-50%

DOF Reality Professional 6-Axis Helicopter Motion Simulator Platform - P6 - Image 1

DOF Reality Professional 6-Axis Helicopter Motion Simulator Platform - P6 - Image 2

Click to enlarge

DOF Reality Professional 6-Axis Helicopter Motion Simulator Platform - P6

DOF Reality Professional 6-Axis Helicopter Motion Simulator Platform - P6 - Image 3

DOF Reality Professional 6-Axis Helicopter Motion Simulator Platform - P6 - Image 4

DOF Reality Professional 6-Axis Helicopter Motion Simulator Platform - P6 - Image 5

DOF Reality Professional 6-Axis Helicopter Motion Simulator Platform – P6

Name: DOF Reality Professional 6-Axis Helicopter Motion Simulator Platform - P6 - towertotower.co.uk
SKU: DOF-P6eH-PRO
Price: 4733.64 GBP
Availability: InStock

Original price was: £9,467.27.Current price is: £4,733.64.

Add to compare

Add to wishlist

SKU: DOF-P6eH-PRO Tags: 6-Axis Helicopter Simulators, Helicopter Motion Simulators, Motion Simulator Platforms

Description

The DOF Reality PRO 6 is the ideal professional-grade 6-axis motion simulator platform for pilots who seek the most realistic helicopter experience possible. It excels in helicopter simulation while also supporting fixed-wing flight and racing without any drawbacks.

The key innovation is the additional gearbox on each motor, providing extra smoothness and precision for the slow, delicate motions essential in helicopter flight — from hover drift and tail rotor corrections to coordinated turns, descent, and ground effect.

Just like in a genuine rotorcraft, the full-motion design moves your entire cockpit — seat, monitor, cyclic, collective, throttle, pedals, joystick/yoke — together, simulating authentic g-forces through muscle pressure and body contact. Powered by highly customizable Sim Racing Studio (SRS) software, it delivers precise telemetry-based feedback for rotor torque, ground effect, turbulence, vibrations, and more.

Why It Stands Out

True 6-Axis Helicopter Motion

Full 6DOF (heave, surge, sway, pitch, roll, yaw) with separate front/rear roll centers and gearbox-enhanced smoothness for ultra-precise low-speed helicopter maneuvers.

Ultra-Smooth Gearbox Enhancement

Additional gearbox on each motor delivers exceptional smoothness and precision, especially critical for hover drift, tail rotor corrections, and delicate rotorcraft control.

Full Cockpit Motion

The entire cockpit moves together — seat, monitor, cyclic, collective, throttle, pedals, and joystick/yoke — for cohesive, in-cockpit g-force feedback and realism.

Multi-Genre Versatility

Excellent performance in helicopter simulation while also handling fixed-wing flight dynamics and racing cues seamlessly.

Professional Grade Build

Robust commercial-grade construction with high pilot weight capacity (440 lbs) makes it suitable for serious training, flight schools, and enthusiast use.

What’s Included

Ready-to-Play Package

Rigid metal motor covers
Metal rig for normal & F1 pose
Mounts for seat or sliding rails
Integrated power drive motors with gearbox enhancement
100-240V control unit with USB
SimRacingStudio license
Quick assembly tools
1-year full warranty

Note

Plug-and-play motion platform only. Customer provides own seat, VR headset, and controllers (cyclic, collective, pedals, throttle, etc.). The PRO 6 supports all major brands and types.

Specifications

Degrees of Freedom	6 DOF (Pitch, Roll, Yaw, Surge, Sway, Heave)
Full Platform Motion	Yes
Range of Motion	17°
Speed	75 cm/s (105°/s)
Torque	28 N/m
Acceleration	0.5G all directions
Power Consumption	1500 Watt (peak)
Box Weight (Size)	1) 60kg (80 × 70 × 30cm) 2) 65kg (80 × 70 × 30cm)
Floor Footprint	4×5 ft, 2 ft H (120×150 cm, 60 cm H)
Material	Commercial grade metal profiles
Supported Pilot Weight	440 lbs / 200 kg
Warranty	Full 1 year (extensions available)

Frequently Asked Questions

What makes the DOF Reality PRO 6 the best 6DOF helicopter motion simulator platform?

The PRO 6 delivers true 6DOF (heave, surge, sway, pitch, roll, yaw) with separate front/rear roll centers, gearbox-enhanced smoothness for low-speed precision, full-rig motion for authentic g-forces, and SRS telemetry optimized for helicopter cues like hover drift, tail rotor corrections, turbulence, and rotor effects.

Can the PRO 6 be used for fixed-wing flight and racing as well as helicopter simulation?

Yes — it’s fully versatile with complete 6DOF motion that handles flight climbs/descents, coordinated turns, and racing acceleration/braking/traction loss seamlessly, no hardware changes needed.

What cockpit components move on the DOF Reality PRO 6 platform?

Full-motion rig moves everything together — seat, monitor, cyclic, collective, throttle, pedals, joystick/yoke — for cohesive, in-cockpit immersion and realistic g-force feedback.

Which helicopter simulators are compatible with the PRO 6?

Powered by Sim Racing Studio (SRS), it supports major titles like DCS World (helicopter modules), Microsoft Flight Simulator, X-Plane, and more via telemetry.

Is the PRO 6 suitable for professional helicopter training or flight schools?

Yes — its full 6DOF motion, smooth gearboxes, and robust build make it ideal for procedural training, muscle memory development, and commercial setups. For certified programs, verify local aviation authority requirements.

How much space is required for the DOF Reality PRO 6?

Footprint is approximately 120 × 150 cm (4 × 5 ft) with 60 cm height. Allow extra clearance (50–100 cm around) for motion travel and safe access.

What warranty and support come with the DOF Reality PRO 6?

Includes a full 1-year warranty with optional extension. 24/7 global support from DOF Reality ensures quick help with setup, tuning, or issues.

Shipping & Returns

Shipping Policy

We offer free shipping on all DOF Reality motion simulator platforms and accessories to the lower 48 contiguous United States. Trusted carriers like FedEx or DHL handle fast, insured delivery (typically in two large boxes for the platform, plus separate packaging for extras).

Shipping Timeline

Orders ship within 5-10 business days after payment clearance. Total delivery time is usually 3-4 weeks from order date. Tracking information is provided by email.

International Buyers

Platforms ship from Europe. International buyers may be responsible for customs duties, tariffs, taxes, or brokerage fees (not included in pricing). Use HS code 9504 50 00 00 for estimates.

Returns & Refunds

Accepted only for verified manufacturing defects that cannot be resolved through troubleshooting or parts replacement. No returns for change of mind due to size and weight. Approved returns require customer-paid shipping; refunds issued within 20 business days after inspection.

Cancellations

Possible within 14 days for non-custom items (subject to approval). No cancellations on custom builds or once shipment has started.

Warranty

Full 1-year manufacturer warranty covers design, material, or performance defects under normal use. Does not cover normal wear, misuse, or unauthorized repairs. Contact support for troubleshooting or claims.

Need Assistance?

Email support@alphacavehq.com — we’re here to make your experience seamless.

Product Manuals

Assembly Instructions & Manuals

The official DOF Reality guide includes step-by-step assembly for the 6 DOF platform, software setup, tuning, VR motion compensation, troubleshooting, and technical specifications.

DOF Reality PRO 6 6-axis helicopter motion simulator platform

Official Assembly Video: Watch the full tutorial for visual guidance on assembling your PRO 6 platform.

Download Full Official Manual (PDF)
